產品規格表
MACHINE SPECIFICATION
|
MODEL |
ITEM |
MT-108 |
MT-108M |
|
SWING OVER BED |
mm |
570 |
|
|
SWING OVER CROSS SLIDE |
mm |
345 |
|
|
MAX. TURNING DIA. |
mm |
380 |
280 |
|
MAX. TURNING LENGTH |
mm |
260 |
228 |
|
CHUCK SIZE |
inch |
8 |
|
|
SPINDLE DRIVE MOTOR |
kw |
7.5/11 |
|
|
SPINDLE SPEED RANGE |
rpm |
4500 |
|
|
NO. OF TOOL STATIONS |
|
10 |
12 |
|
GUIDEWAYS |
|
HARD RAIL |
|
|
MACHINE WEIGHT (N.W.) |
kg. |
3350 |
|
STANDARD ACCESSORIES
|
3-jaw hydraulic chuck |
Leveling pads |
O.D. tool holder |
|
Hydraulic tailstock |
Soft jaw |
Facing tool holder |
|
Hydraulic system |
Live center |
Boring bar holder & sleeves |
|
Coolant system |
Foot switch for chuck clamp |
Drill sleeves |
|
Auto lubrication system |
MPG hand wheel |
Operation & maintenance manuals |
|
Work light equipment |
Tool box |
|
|
Heat exchanger |
Morse taper sleeve |
|
|
※Tool holders & sleeves are optional for living tool. |
||
